OJ-400x2 dual channel continuous roll coreless flat mouth garbage bag making machine

DATA:2022/1/7 Publisher: Oujie Machinery



Performance and features

1.Computer automatic control, automatic counting and adjustable counting alarm, high efficiency, saving manpower and time.

2.From film roll to finished bag, it is fully automated and completed in one go;
3.Domestic servo motor with fixed length, photoelectric tracking, accurate and stable, feeding adopts photoelectric control;

4.Adopting a hot cutting device and an intelligent temperature control system to ensure a firm and smooth sealing of the bag opening
5.The host adopts a frequency converter to control speed regulation;
6.Material feeding is controlled by a frequency converter.

Main technical parameters

  Machine model
  OJ-400x2
  Bag-making width
  100-180mm
  Bag length
  400-1200mm
  Machine speed
  50-200pcs/min
  Bag thickness
  0.006-0.025mm
  Sealing method
  Chipless flat mouth garbage bag (star bottom)
  Heating total power
  8kw
  Temperature control range
  4 Zone
  Total power
  20kw
  Machine weight
  2000kg
  Machine dimensions
  6200*2000*1750mm
