OJRF Automatic biodegradable shopping bag making machine

DATA:2022/1/7 Publisher: Oujie Machinery


Description:

This machine is specializing in manufacturing biodegradable T-shirt/vest shopping bags. Heat sealing knife and cutting knife are designed together in order to achieve non-stretch bag making and speed improving. It can punch flat bag to t-shirt shopping bags automatically. With it’s two servo motor’s support, it can make different size printed bags in two lines at the same time.


Features:

With photocell for printed film;
Intelligent temperature control system;
Static electricity removing system;
Inline automatic punchers to cut handles of shopping bags;
Using touch screen computer control;


Specifications:

Model OJRF 400*2
OJ 500*2
Width of bag making 100-350mm 100-450mm
Length of bag making
100-650mm 100-650mm
Speed of bag making
200-300 bags/min*2
200-300 bags/min*2
Thickness of bag making 0.01-0.06mm
Usage of machine produce T-shirt/vest shopping bag piece by piece
Total power 15kw
Weight 1800kgs
2000kgs
Dimension of installation 6000*1550*1800mm
6000*1700*1800mm
Voltage of machine 220V, 50Hz,single-ph

Applications:
